  • One socket supports :
    MS : MS, MS PRO, MS PRO HS, MS v1.43, MS-Pro v1.02 MS Duo, MS PRO Duo,
    MS PRO Duo HS, Micro-MS(M2)(with adapter)MS ROM, MS Memory Select Function
    XD : XD, XD-H, XD-M, XDv1.2
    SD : SD, SD1.1, SD2.0(SDHC)
    Mini SD (with adapter), microSD/ T-Flash (with adapter)
    MMC : MMC, MMC Plus, RS-MMC, RS-MMC4.0, RS-MMC Plus, MMC mobile,
    MMC v4.2MMC-micro(with adapter) .
  • ID Special Design, accepts four types of flash cards(MS, XD, SD, MMC) along with a built in flash card holder.
  • Active LED indicators show when card is inserted or busy (read/write).
  • Support Plug and Play, Hot-Swapping.
  • Support USB2.0 Hi-Speed (480Mbps) Model/USB 1.1 Full-Speed (12Mbps) Model.
  • USB powered; no external power required.
  • Operating temperature: 0oC~70oC
  • Storage temperature: -40oC~150oC
  • Relative Humidity: Operating RH: 50% Storage RH: 95%(Max without condensing)
  • Runs at 12MHz crystal.
  • Card Power Output Current Range:
  • SD/MMC max:220mA
  • MS/MS-Pro max250mA
  • XD max120mA
  • Supply Voltage : -0.5V to +5.5V electrical characteristics.


  • IBM Compatible PC and Mac PC
  • USB Host card or USB Hub device
  • OS: WindowsME/2000/XP & Mac OS X; Windows 98/2000 and Mac OS 9
  • Drivers are available.
  • Agency approvals: CE, FCC, ROHS
