   Specification:
   MP3 Player:
Category Description Availability
Playback Mode MP3 Yes (Sigmatel 3510 CPU)
WMA Yes
WAV Yes
EQ Modes Normal/ Rock/ Jazz/ Classical/ Pop/ Bass/ Treble
ID3 Tag Display Yes
Synchronous Lyrics Windows Media Player, Lyrics Power
Bluetooth Playback Time 6 Hour
Playback Time 15 Hours
Microsoft DRM TBD
Record Mode Line-In Recording No
Mic Voice Recording Yes
FM Recording Yes
Sampling Rate 8/11/22 KHz
Stream Format ADPCM
Record Audio Format WAV
Recordable Time Max. 36 Hours (With 512MB)
Category Description Availability
FM Radio (built-in) FM Function Yes (Option)
FM Recording Yes
Preset Channels 20 sets
Frequency Range 76- 90 MHz / 87.5-108 MHz
Channel Save Yes
USB Interface USB Mass Storage Yes
USB 2.0 Hi Speed Yes
Read 3.2MB/s
Write 2.6MB/s
Connector Mini USB
Display Interface OLED/ LCM Display Yes
Screen Color Yellow & Blue 2 Colors (OLED Display)
Screen Resolution 128 x 64 (OLED Display)
Contrast 100:1 (OLED Display)
Brightness 100 (OLED Display)
Graphic User Interface Bitmap
Category Description Availability
Setting Mode Contrast Adjustable No
Power Saving Mode 3 settings
Multi-Language GUI More than 2 countries
REC Sample Rate Yes
Welcome Screen Yes
Audio Quality Signal to Noise Ratio 95dB
Total Harmonic Distortion Output 0.08%
Output (per channel) 5mW
Frequency Response 20Hz-20KHz
Firmware Upgradeable Yes
Hot Key Bluetooth/ REC/ Power/ Play/ Hold
Multi-Language GUI EN/ TC
Power Supply 720mAh Li-Polymer Battery
Memory Size 256MB/512MB/1GB
Certificated CE/ FCC/ BSMI/ C-Tick
Dimension 80.85 x 35.75 x16.6 mm
Net Weight 49 g

Stereo Handset:

Standards Bluetooth specification v1.2 compliant
Bluetooth Profiles Supported A2DP (Advanced Audio Distribution Profile) HSP (Headset Profile), HFP (Hands-Free Profile)
Radio Frequency 2402MHz~2480MHz
Modulation Method GFSK (Gaussian Frequency Shift Keying)
Transmitter Output Power -2~+4 dBm
Receiver Sensitivity < -80 dBm
Distance 10 meters up to 20 meters (open area)
Audio Format SBC (Sub-band Codec)
Audio Frequency Range 20Hz ~ 22kHz
Power Supply Lithium Lon Battery
Button/Switch Power On/Off Volume up/down Phone accept/hang up/mute*
LED Indicators Blinking (pairing) Steady on (connected)
Color White, Gray, Black
Dimensions Folded: 70 mm (L) x 95 (W) x 60 (H)mm Unfolded: 150mm (L) x 110 (W) x 65 (H)mm
Weight About 200 grams
Environment Operating temperature: 0 to 55 C Operating humidity: 5-95%, non-condensing
