FEATURES:
  1. 20GB high capacity for data storage
  2. MP3/WMA/VBR music playback
  3. abt.5000 songs (hundreds albums) for 20GB HDD Music Jukebox
  4. USB 2.0 interface and support USB 1.1 Host function for data transfer
  5. Stereo audio effect
  6. User-friendly Interface Design
  7. High Quality Aluminum Design
  8. LCD Remote Controller is available
SPECIFICATION:
  1. Pocket-size Music Jukebox with hundreds albums
  2. (abt.5000 songs for 20GB HDD Music Jukebox)
  3. MP3,WMA, VBR music playback (OGG optional in future)
  4. Support MP3 Line-in encoder
  5. FM Radio with channel presets.
  6. Support music file containing lyric
  7. Support Firmware upgrade
  8. Support Reset function: Press reset hole when system stuck
  9. 6 EQ: NORMAL, CLASSIC, ROCK, JAZZ, Live, USER's EQ
  10. 3D Sound Effect:
  11. SRS(3D+High Frequency) / TruBass (Ultra Deep Bass)
  12. adjust 10 levels each (level1 to level10)
  13. Repeat: REPEAT One Song, REPEAT FOLDER, Repeat All FolderShuffle One Song, Shuffle FOLDER, Shuffle All Folder, Section Repeat (A-B)

HARDWARE:

  1. Built-in 20G Hard Disk (Toshiba 1.8')
  2. LCD Display:
  3. ?? 128*128 dot matrix LCD with Blue EL backlight
  4. ?? 2 bit 4 grayscale / 8 lines
  5. High quality aluminum housing design
  6. LCD Remote Controller is available
  7. Compatible with USB 2.0 specification, Plug & Play
  8. Support USB 1.1 Host function
  9. Audio Support: Playback MP3,WMA, VBR (OGG optional)
  10. ?? Built-in FM Tuner support 20 preset
  11. ?? Auto scan / auto memory function
  12. MP3 Line-in Encoder
  13. Compatible with USB2.0 specification and support USB1.1 Host function
  14. Headphone: 15mW(L) + 15mW(R) at 16 Ohm max volume

POWER SUPPORTING:

  • Built-in rechargeable LITHIUM-POLYMER battery (1300mAh)
  • Full charge Time 3 hours,
  • Quick-charge: 1 hour (charge to 70% of battery capacity)
  • Playback time 12 hours plus

Operating Environment

  • Operating Temp: Read: -10!~65!, Write: 5!~65!
  • Frequency Response: 200Hz ~ 20,000 Hz
  • S/N: 85 dB (with a filter at 16 Ohm Load)
  • THD: 0.1%

O/S supporting MICROSOFT WINDOWS 98/SE/ME/2000/XP, MAC OS 9.X , 10.X

Approvals CE, FCC certificates
Dimension 98 x 60 x 24 mm
PACKAGE & ACCESSORIES:
  1. HDD MP3 Player
  2. Colorful Retail Box
  3. ADAPTOR FOR RECHARGE
  4. USB CABLE
  5. ENCODING CABLE
  6. USER's MANUAL
  7. STEREO EARPHONE
  8. BUNDLED CD (USB DRIVER FOR WINDOWS 98 USERS and User's Manual)
