Features and Characteristics

• Connects up to 4 HDMI sources (inputs) to one HDTV display device (output).
• Maintains 480i, 480p, 720i, 720p, and 1080p resolutions.
• Maintains highest HDMI single link video resolution and digital audio signal
• Works with HDCP – compliant device.
• Both HDMI-HDMI and DVI-HDMI cables can be used to connect the input and switch output
• Input can be selected from either the IR remote controller (included) or through the front panel “input select” button.


Video Amplifier
Bandwidth: 2.25Gbps
Input Video Signal Specification: 1.3a
Input connector type: 4 HDMI 19pin female
Output connector type: 1 HDMI 19pin female
Total Cable Length Supported: Up to depends on type of cable used
Power consumption: Max. 5V/350mA
Power supply:5V DC, 1A
Dimensions (mm): 176(L) x 25(W) x 82(H)
Product weight (NET): 350g
FCC: This device is tested to be in conformance with FCC part 15 Class B

Package Contents

•1 x HDMI 4 x 1 Switch
•1 x 5V DC 1A power supply
•1 x Infrared Remote controller
•2 x AAA batteries for remote control
•1 x Instruction booklet
